425oz CNC Plasma Cutter CNC Plasma Cutting Machine Wantai 4.2A Motor-in 4-driver DQ542MA 4.2A 50V 128micro Hybrid 112CM Axis NEMA 23 Kit 4 CNC Stepper Motor NEMA 23

1 Piece
MOQ
$272.56(1 - 9 Pieces) $235.30(10 - 49 Pieces) $200.10(50 - 99 Pieces) $181.71(>=100 Pieces)
Preis
425oz CNC Plasma Cutter CNC Plasma Cutting Machine Wantai 4.2A Motor-in 4-driver DQ542MA 4.2A 50V 128micro Hybrid 112CM Axis NEMA 23 Kit 4 CNC Stepper Motor NEMA 23
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Model Number: WT57STH115-4204A
Phase: 2
Type: Hybrid
Current / Phase: 4.2A
Product name: WT57STH115-4204A
Holding Torque: 425oz-in
Key words: cnc stepper motor kit
Frame Size: 57mm*57mm
Motor length: 112CM
Application: CNC Plasma Cutting Machine
Voltage: 3.78V
Shaft: round
Motor type: Stepmotor Nema 23
Brand: wantai
Zertifizierung: ce, ISO, RoHS
Grundinformation
Zertifizierung: ce, ISO, RoHS
Model Number: WT57STH115-4204A
Zahlung und Versand AGB
Produkt-Beschreibung







This item includes:



4 pcs Nema 23 stepper motor WT57STH115-4204A  4.2A 30Kg.cm(425oz-in)



4 pcs stepper motor driver DQ542MA 4.2A



2 pcs power supply:350W 36V



1 pc breakout board&cable











General Specification:

Step angle accuracy: + - 5%(full step,not load)

Resistance accuracy: + - 10%

Inductance accuracy: + - 20%

Temperature rise: 80deg Max(rated current,2 phase on)

Ambient temperature ----------—20deg ~+50deg

Insulation resistance:100MΩ  Min,500VDC

Insultion Strength--------500VAC for one minute





 1)stepper motor



Datasheet(WT57STH115-4204A ,4.2A, 425oz-in holding torque)



PHASE 2 PHASE
STEP ANGLE 1.8 STEP
VOLTAGE 3.78V
CURRENT 4.2A /PHASE
RESISTANCE 0.9
INDUCTANCE 3.8
HOLDING TORQUE 280.cm
DETENT TORQUE 12N.cm
INSULATION CLASS B
LEAD STYLE AWG26 UL1007
ROTOR TORQUE 800.cm





BLACK           A+

GREEN           A-

RED                B+

BLUE              B-









 2)stepper motor driver







 DQ542MA is a type of two-phase hybrid stepping motor driver, the drive voltage of which is from 18VDC to 50VDC. It is designed for use with 2-phase hybrid stepper motor of all kinds with 42mm to 86mm outside diameter and less than 4.0A phase current. This circuit that it adopts is similar to the circuit of servo control which enables the motor run smoothly almost without noise and vibration. Holding torque when DQ542MA run under high speed is also significantly higher than the other two-phase driver, what’s more, the positioning accuracy is also higher. It is widely used in middle and big size numerical control devices such as curving machine, CNC machine, Computer embroider machine, packing machines and so on.





Features:

High performance, low price

Average current control, 2-phase sinusoidal output current drive

Supply voltage from 18VDC to 50VDC

Opto-isolated signal I/O

Overvoltage, under voltage, overcurrect, phase short circuit protection

15 channels subdivision and automatic idle-current reduction

8 channels output phase current setting

Offline command input terminal

Motor torque is related to speed, but not related to step/revolution

High start speed

High holding torque under high speed

Electrical specification:





Input voltage

18-50VDC

Input current

< 4A

Output current

1.0A~4.2A

Consumption

Consumption:80W;  Internal Insurance:6A

Temperature

Working Temperature -10~45℃;

Stocking temperature -40℃~70℃

Humidity

No condensation, no water droplets

gas

Prohibition of combustible gases and conductive dust

weight

300GS





3) power supply









4) breakout board













We are specializing in Stepper Motor, Brushless DC Motor, Stepper Geared
Motor, Servo Motor, Motor Driver and the Control System. And we also
provide professional OEM service, manufacture high-quality customized
products.







1. Do all products in stock?
Sure. All goods can be shipped in 5days if no problems happen!
2.What about the Min. order Quantity?
All products have stock. Customer can order even 1PC.
3.How about the warranty?
We have confident for our product. Every product support 1 years warranty. For sure our products are of high quality control, and have competitive price and we have excellent after sale services.
4. Can you offer OEM or ODM for products?
Yes,we have professional design team and has established the largest software R&D center, we believe we can satisfied all your needs.
5.How to do the payment?
Payment we accept: alibaba. T/T. L/C.Western union. moneygram and Paypal.
6.What is the shipping?
We can provide express,air and sea shipping according to customer requirements.
We will do confirmation with customer!
